Flat Return Tru-Trainer, conveyor belt tracking system

The Tru-Trainer series of conveyor belt tracking idlers are a patented design that offers the most reliable and re-active tracking idlers available today. Its stainless steel internal pivot that is perpendicular to the plane of the belt and its rubber covered shell and tapered ends helps actuate the trainer immediately as the belt moves off center. It is always reacting to keep the belt centered. It does not wait, like conventional trainers, for the conveyor belt to walk over to 90-degree sensor rollers and then have the belt react. The Flat Return Tru-Trainer reacts as the belt tracker moves off center it will contact the tapered section of the roller on that side of the conveyor belt. The effect of this will be to force the roller to rotate on its central pivot causing the belt to come back to its original position (centered).

Continuous Alignment - by always tracking the belt to the center of the conveyor, it reduces edge damage, spillage and overall better conveyor belt tracking performance.
Heavy-Duty - design of our trainer uses 3 7/16" bearings, 1 3/4" shaft, and an abrasive resistant hot-vulcanized rubber cover. Urethane and ceramic covers are also available.
Patented Design - does not rely on the conveyor belt to activate an arm-type tracking mechanism. By utilizing an internal pivot versus external pivot it does NOT build up with carry back.
Reactionary - in both wet and dry conditions as seen in below ground and above ground mining all over the world.
Total Satisfaction Guarantee (TSG) – to solve your conveyor belt tracking problems and make your overall conveyor system run more efficiently.
Excellent for Reversing Belt Applications
Can be used on the Clean Side of the Belt

Tru-Trainer Brochure

Tru-Trainer Installation Instructions

Tru-Trainer Flat Return,
The best conveyor belt tracking
idler on the market today!

Flat Return Tru-Trainer in application.

Tru-Trainer Conveyor Belt Tracking Video:
A six minute video of Tru-Trainer belt tracker in action.
Tru-Trainer DVD
