URETHANE CANOE LINERS

Design Features

Standard sizes available in 1”, 2”and 3” thickness
9” wide and 48” long
Available in beveled edge or square edge
Slotted holes on 12” centers for ease of adjustment in the tightest applications
Liners can be adjusted easily up or down to achieve the best fit
Custom sizes available on request.

ENGINEERED TO ABSORB IMPACT & ABRASION

ASGCO^® Urethane Canoe Liners are made from our exclusive urethane compound with a durometer of 80/85, along with steel backing plate for extra added support. These type of liners are very effective, especially where material is being bulk loaded to help control leakage in and around load zone areas. ASGCO^® Urethane Canoe Liners are a key solution in decreasing downtime and increasing production due to spillage, while maintaining a safe working environment.

PRODUCT SPECIFICATIONS

Applications – In load-zones with high tonnage rates.

Steel Backing – for extra support

Standard Size Available – 1”, 2”, and 3” thickness

Custom sizes available at customers request.

Part Numbers

Urethane Canoe Liners with Steel Backing (Beveled & Square)

Internal Urethane Canoe Liners are available in custom sizes on request

The Mounting Hardware is Included

Part Number	Description	Size	Weight Lbs
M-ASG-U-CL-48X9X1-B-1	Urethane Canoe Liner Beveled 1" thick x 9" wide x 48" Long	48" x 9" x 1"	36
M-ASG-U-CL-48X9X2-B-1	Urethane Canoe Liner Beveled 2" thick x 9" wide x 48" Long	48" x 9" x 2"	50
M-ASG-U-CL-48X9X3-B-1	Urethane Canoe Liner Beveled 3" thick x 9" wide x 48" Long	48" x 9" x 3"	64
M-ASG-U-CL-48X9X1-S-1	Urethane Canoe Liner Squared 1" thick x 9" wide x 48" Long	48" x 9" x 1"	37
M-ASG-U-CL-48X9X2-S-1	Urethane Canoe Liner Squared 2" thick x 9" wide x 48" Long	48" x 9" x 2"	51
M-ASG-U-CL-48X9X3-S-1	Urethane Canoe Liner Squared 3" thick x 9" wide x 48" Long	48" x 9" x 3"	65
